1. Charging for 8 hours and runs 100 km.
2. Independently designed quasi-towing frame that can tow any tools or other equipments within 500 kg.
3.The patented design of the pusher frame, rear-wheels drive forward, flexible and convenient.
4.Maintenance-free batteries eliminate the traditional liquid replenishment process, preventing damage to the battery caused by forgetting to add liquid.
Specifications: 48V-72V
Product details:
名称 | 参 数 | |
动力部分 | 型号规格 | 9DT-60V |
品 牌 | 意美特 | |
车辆型号 | 自制 | |
驱动形式 | 后驱动 | |
行走方式 | 电动 | |
整机传动方式 | 液压 | |
行走电机功率 | 60V1000W | |
转向形式 | 前转向 | |
电瓶品牌及容量 | 锂电瓶 | |
电瓶伏数 | 60V | |
整机电瓶数量 | 1 | |
行走速度 | 15公里/小时 0-25公里 | |
轮胎数量 | 4 | |
轮胎型号 | 前转向轮4.00-8 后驱动轮145/70R12 | |
多路阀型号 | 2D-L10E-T-40 ZT-12E-OT-40 | |
毛刷旋转马达型号 | BM1-50 | |
扫地刷规格 | 长500mm*直径420mm | |
油缸数量 | 3 | |
油缸规格 | 60*37/60*42/60*47 | |
充电时间 | 5-7小时左右 | |
续航能力 | 10小时以上 | |
整体尺寸 | 约2300*1500*1400mm | |
重量 | 约680KG | |
注:可加选项根据客户需求添加推料板对饲料草进行推送,侧面刷子进行清扫,后部带牵引架,可一机多用 |
